H96max M7 Android 13.0 TV Box RK3528 8K UHD Video Smart TV Box with Dual Speakers Support 2.4G/5G Dual Band WiFi&BT5.1 Media Player TV Receiver Home Theatre Set Top Box with Remote Control Free Adapter UK AU EU US Plug

$133.69

CHECK PRICE

Description

Specification:

CPU

Quad Core ARM Cortex-A53

GPU

Mali-450
        Memory 2GB/4GB
           Flash 16GB/32GB

WiFi

WLAN 802.11a/b/g/n/ac

bluetooth

BT V5.1

Software

OS

Android 13.0

Video

Video Decoder

·Real-time video decoder of
MPEG-1, MPEG-2, MPEG-4
H.263, H.264/AVC, H.265/HEVC, MVC
VC-1
AVS, AVS+,AVS2
·MMU Embedded
·Supports frame timeout interrupt, frame finish interrupt and bit stream error interrupt
·Error detection and concealment support for all video formats
·Output data format YUV420 semi-planar, YUV400(monochrome), YUV422 is
supported by H.264
·H.264/AVC BP/MP/HP profile @ level 5.1; H.264/AVC MVC; up to 4Kx2K@60fps and 8K*4K@23fps
·H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K@60fps and 8K*4K@23fps
·AVS2 4KX2K @60fps
·MPEG-1, Main profile, up to 1080P@60fps
·MPEG-2, SP@ML, MP@HL, up to 1080P@60fps
·MPEG-4, ASP profile @ level 5, up to 1080P@60fps
·AVS, Jizhun profile @ level 6.0; up to 1080P@60fps
·AVS-P16 (AVS+), up to 1080P@60fps
·H.263, up to 576P@60fps
·VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P@60fps

·Video Encoder
·Support video encoder for H.264, HP@level4.2
·H.264 maximum frame rate is up to 1920×1080@60fps
·Capable of encoding HEVC Main Profile @ L4.1 High-tier
·H.265 resolution and frame rate are up to 1920×1080 @60fps
·JPEG encoder included

·JPEG decoder
·Input JPEG file : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 sampling formats
·Output raw image : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 semi-planar
·Decoder size is from 48×48 to 8176×8176(66.8Mpixels)
·Support JPEG ROI(region of image) decode
·Maximum data rate is up to 76million pixels per second

·Video OUT
·Display Interface
·Support HD 2.0b output up to 4K 10bit @60Hz
·TV interface: TV encoder 10bit out for DAC
·HD interface:
24 bit (RGB888 YCbCr444), 30 bit(RGB101010,YCbCr 420, YCbCr 444)
Max output resolution 4K for HD, 480i/576i for CVBS

·HD
·Compliant HD 2.0b
·Support YUV420 4k x 2k @ 60fps
·Support for 4k x 2k and 3D video formats
·Support for up to 10.2bps bandwidth
·Compliance HD compliance Test specification 1.4 and 2.x
·Support HDR10, HLG HDR, Vivid HDR

Audio

Supports MP3, AAC, WMA, RM, FLAC
         Image HD JPEG、BMP、GIF、PNG、TIF

bluetooth Solution

JL AC6965A V5.1
      bluetooth             Version V5.1+BR+EDR+BLE specification

Language

Multi-Language support

Applications

Online

Browse all video websites,support Netflix,Hulu,Youtube, etc.

Apps

Apps download freely form Google Play、Apkpure store etc.

Medium

Local Media playback,Support HDD, U Disck

Talk Online

Support SKYPE ,MSN , facebook ,twitter ,QQ etc
       Others Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard

Interface IN/Output

I/O

1×HD

4K*2K UHD Output

1×USB

1*USB2.0
1×DC 12V/4A

1×TF

Support


Features:

1. Android 13.0 Smart TV Box: Highly optimized for smooth and efficient performance for all kinds of apps and games that you can download from Google Play Store.

2. Dual-Speaker Home Theatre System: Provides high-quality audio output with an enriched bass experience for an immersive sound experience.
3. Superior Video Quality: Supports 8K UHD video decoding, providing crystal clear and highly detailed video quality.
4. Dual-Band WIFI & bluetooth 5.1: Ensures fast and stable network connectivity. Also includes bluetooth 5.1 for easy pairing with other devices.
5. Online OTA Firmware Upgrade: Keeps your device always updated to the latest software with the support of over-the-air firmware upgrades.

Package Include:

1× TV BOX
1× HD Cable
1× Remote
1× Power Adapter
1× Packing Box
1× User Manual

Additional information

Weight 1.1 kg
